Type: Hot rolled (heavy/large/medium/small) H Beams, Angle, Channel, I Beam, U Beam;
Specification(Customizable special sizes):
H Beam | H100 ~ H1150 |
W4 ~ W44, HP8 ~ HP18 | |
HEA/B100~HEA/B1000, HD260~HD400, HP200 ~ HP400,
UB127 ~ UB1016, UC132 ~ UC356, UBP203 ~ UBP356 |
|
12B1~70B2, 20SH1~100SH4 | |
Angle | L20 ~ L250, L90*75~ L400*100, L3/4*3/4 ~ L5*3 1/2 |
Channel | U75~U380, MC 6 ~ MC 18, UPN50~UPN400,UPE80~UPE400, PFC75~PFC430, CH76~CH432 |
I Beam | IPE80 ~ IPE750, IPN80~IPN600, S75~S610, IB100~IB600 |
U Beam | 29U, 36U |
Technical standards:
World mainstream standards such as national standards, Japanese standards, Korean standards, American standards, European standards, Russian standards, Australian standards, etc
EN10034/10163/10056/10206/10207/10279, BS4, JIS G 3192, GB/T 11263/706, ASTM A6/A36, AS/NZS3679, KS D3502…
Material Grade:
EN10025-2/3/4/5/6, ASTM A131/A572/A690/A992, JIS 3103/3113, GB/T 700/714/ 4171/ 1591, YB/T 4274/4620…
S235JR~S355J2/K2~S890QL1, A36, A992, A572/690 GR 42~GR 70, SS330~SS540, SAPH310~SAPH440, Q235B~Q500ME, Q245HYB~Q460KZB-E…
Usage:
Widely used in steel structure engineering in the fields of buildings, bridges, energy (Electric-transmission/oil and gas/marine platform), boilers, railways, vehicles, etc
